SM SERIES
Flail / Mulching heads suitable for machines from 3.5 to 8.0 tons.
Ideal for carrying out reclamation work on grass and shrubs, even in confined spaces, the SM SERIES has a compact and robust design that makes it versatile for works in various sectors, such as construction, public and private green maintenance, etc.
Maximum cutting size Ø8 cm
Features
Compact and robust design
Frame with double cavity bottom, reinforced up to the point of connection with the front chains for greater impact resistance.
Spherical roller bearings are better protected from impurities thanks to a labyrinth of special seals.
Shaft with blades or hammers with fixed supports for a better shredding of the materials
Spiral-mounted tools for a better cutting performance
Direct transmission
Flow control valve – shockproof valve – anti-cavitation valve – max pressure (it does not require drainage pipe)
Possibilità di equipaggiare il rotore con mazze o coltelli a Y
Internal toothed bar that helps to chop the material
Rear blade in rubberized, multi-layered, and tear-proof canvas
Support roller with through shaft for greater resistance
Wear-resistant and replaceable skids
Protection devices in compliance with current European Regulations according to CE norms
Bolted steel plate where to prepare the machine connection (not painted)
Available in three different cutting widths: 900mm, 1100mm & 1300mm (with Y-Blades or Hammers)
